20 Gallon Two Stage Gas Air Compressor | Mi-T-M

Brand Mi-T-MSKU AM2-PH09-20M
Original price $3,830.00 - Original price $5,226.00
Original price
$4,549.00
$3,830.00 - $5,226.00
Current price $4,549.00
Authorized Dealer Sourcing
Financing Available for Eligible Orders
Contractor-Grade Equipment

Shipping: LTL freight. Commercial delivery preferred.

20-gallon two-stage gas air compressor, 17.2 CFM at 175 PSI, ASME-certified receiver tank, for remote jobsites that need dependable power. Choose Portable (flat-free tires, $237-244 more) or Stationary mount, and Honda or Mi-T-M engine, each with an electric-start option. Electric-start models don't include a battery from the factory.

Need fitment or freight help before you order? Contact our team.

Shipping & Freight

For an order containing products from a single brand, shipping is a flat rate based on your order total:

  • Orders up to $5,000: $279
  • Orders $5,000 to $10,000: $347
  • Orders $10,000 and over: $517

These rates cover standard freight delivery to a commercial address. After you place your order, our team will confirm your delivery timeline within 1 to 3 business days.

Ordering from more than one brand? Multi-brand orders ship on separate freight and are quoted individually rather than at the flat rate above. Place your order or contact us first and we will confirm total freight before anything is finalized.

Liftgate service is not included in these rates. If your delivery location has no loading dock or forklift to unload the freight from the truck, liftgate service is required and will be added to your shipping charge. If you are unsure whether you need it, contact us before ordering.

Commercial delivery locations are preferred when available. Residential delivery, limited-access locations, and appointment scheduling may affect handling.

Lead times vary by product, manufacturer availability, and selected options. Some configured, special-order, or non-stock items require additional processing time before they ship.

Please inspect all freight shipments at delivery before signing. If you see visible damage, note it with the carrier and contact us as soon as possible.

If you need freight, delivery, or lead-time guidance before ordering, contact our team before you purchase.

Compatibility / Fitment

Compatibility varies by product type, machine setup, selected options, and intended application.

For machine-mounted equipment and attachments, buyers should confirm fitment before ordering using the relevant machine information, including model, attachment style, mount type, coupler type, hydraulic requirements, and any other product-specific requirements listed on the page.

Hardscape Heavy can assist with pre-order fitment guidance based on the information you provide. This guidance is limited to purchase and compatibility review before ordering and does not include field installation, hydraulic modification, fabrication, or on-site setup support.

If you are unsure whether a product will work with your machine or application, contact us before placing the order.

Specifications

Core Specs

  • CFM @ PSI: 17.2 @ 175, 150 PSI maximum rated regulator
  • Engine: 270cc Honda GX270 OHV or 300cc Mi-T-M OHV
  • Tank: 20 gallon, ASME receiver tank
  • Mount: Portable (46x26x39.5 in) or Stationary (37x18x38 in)
  • Net Weight: 306-313 lb depending on engine
  • Retail Price: $3830-$5226 depending on mount and engine


Need full technical detail?
See the Technical Details tab. If available, also see manufacturer PDF in the Downloads tab.

Returns & Warranty

Warranty coverage is provided by the product manufacturer where applicable. Warranty terms, coverage periods, exclusions, and claim procedures vary by brand and product type.

Hardscape Heavy does not create separate warranty coverage beyond the manufacturer’s warranty unless explicitly stated on the product page.

Returns are governed by our store return policy. Because many products in this category involve freight shipping, special ordering, or configuration-specific selections, return eligibility may vary by product and condition. Special-order, custom-configured, used, damaged, or installed items may not be eligible for return.

Please review our full return policy before purchase. If you have questions about return eligibility or manufacturer warranty coverage for a specific item, contact us before ordering.

Mi-T-M's 20-gallon two-stage gas air compressor is built for remote jobsites that require dependable power, running from an ASME-certified receiver tank. It comes in both portable and stationary mount configurations.

Portable models ride on flat-free tires for moving between locations; stationary models remove that hardware and cost roughly $237 to $244 less as a result, and stationary is the only mount Mi-T-M rates for the service truck mount kit. Within either mount, the engine choice is Honda or Mi-T-M, each also offered with electric start. Electric-start models don't include a battery from the factory; two separate options exist depending on what you already have on hand, a full kit with the battery included (AX-0017) or just the tray, box, and cables for a battery you supply yourself (AX-0077).

Common Applications

  • Remote jobsites that require dependable power
  • Choosing Portable (wheeled, for moving between locations) or Stationary (bolted down, for a fixed shop or service-truck installation) to match how the compressor will be used

Selection Notes

  • Mount is the first decision: Portable adds flat-free tires and costs $237-244 more; Stationary is the only mount rated for the service truck mount kit (854-0093)
  • Engine choice is Honda or Mi-T-M, each with a factory electric-start option
  • Electric-start battery options differ: AX-0017 includes the battery, AX-0077 is tray/box/cables only for a battery you supply
Unit Specifications
CFM @ PSI
17.2 @ 175, equipped with 150-PSI maximum rated regulator
Engine options
270cc Honda GX270 OHV or 300cc Mi-T-M OHV, both pneumatic idle control; either also available with electric start
Certification
ASME Boiler and Pressure Vessel Code - UM
Build
Compressor pump
Cast iron compressor pump, splash lubricated, stainless-steel braided discharge hose, large canister intake filter, oil level sight indicator
Frame
Powder coated ASME receiver tank, 3/16-inch base plate to reduce vibration, powder coated two-piece belt guard, 13-inch flat-free tires on portable models
Components
Regulator and two gauges for tank and outlet pressure, manual drain valve, 16.5-inch fly wheel, quality pilot valve unloader, start/stop control set at 145 to 175 PSI
Warranty
3 year engine
MountEngineModelShip WeightNet Weight
Portable 270cc Honda GX270 OHV AM2-PH09-20M 356 lb 306 lb
Portable 270cc Honda GX270 OHV, electric start AM2-PH09-20ME 363 lb 313 lb
Portable 300cc Mi-T-M OHV AM2-PM09-20M 356 lb 306 lb
Portable 300cc Mi-T-M OHV, electric start AM2-PM09-20ME 363 lb 313 lb
Stationary 270cc Honda GX270 OHV AM2-SH09-20M 356 lb 306 lb
Stationary 270cc Honda GX270 OHV, electric start AM2-SH09-20ME 363 lb 313 lb
Stationary 300cc Mi-T-M OHV AM2-SM09-20M 356 lb 306 lb
Stationary 300cc Mi-T-M OHV, electric start AM2-SM09-20ME 363 lb 313 lb
Accessories: To order any of these accessories, contact support@hardscapeheavy.com
Part NumberDescriptionFits
854-0093 Service truck mount kit, four rubber isolators Stationary models only
AW-6000-1002 Equipment cover All models
AX-0003 Manual drain/regulator/metal bowl, drains moisture from air system (order-time option, cannot be added later) All models
AX-0017 Battery, battery tray, box, and 2-foot cables, attaches to engine side on unit (order-time option, cannot be added later) Electric start models
AX-0077 Battery tray, box, and 2-foot cables (no battery), attaches to engine side of unit (order-time option, cannot be added later) Electric start models
AX-0101 Remote start/choke, sealed cable, 7-foot wire extension for key switch (order-time option, cannot be added later) AM2-PH09-20ME and AM2-SH09-20ME
AX-0105 Remote start/choke, sealed cable, 7-foot wire extension for key switch (order-time option, cannot be added later) AM2-PM09-20ME and AM2-SM09-20ME

Included with Purchase

  • 1 20 Gallon Two Stage Gas Air Compressor (mount and engine option as ordered)
  • Regulator, two gauges, and manual drain valve

Not Included Unless Stated

  • Battery on electric-start models: AX-0017 (includes battery) or AX-0077 (tray/box/cables only) sold separately
  • On-site setup or fuel

Note: Confirm exact included components with supplier at time of order.
